New The Comfort Master Package

Specifications

Compare >>> Select up to 2 models to compare specifications

John DeereThe Comfort Master Package

Add Model --Please Select-- Gator XUV 825M S4 (Model year 2023) Gator XUV835E (Model year 2023) Gator XUV835M Open (Model year 2023) Gator XUV835R (Model year 2023) Gator XUV835R Signature Edition (Model year 2023) Gator XUV 855M S4 (Model year 2023) Gator XUV865M Cab HVAC (Model year 2023) Gator XUV865M Open (Model year 2023) Gator XUV865R (Model year 2023) Gator XUV865R Signature Edition (Model year 2023)

Add Model --Please Select-- Gator XUV 825M S4 (Model year 2023) Gator XUV835E (Model year 2023) Gator XUV835M Open (Model year 2023) Gator XUV835R (Model year 2023) Gator XUV835R Signature Edition (Model year 2023) Gator XUV 855M S4 (Model year 2023) Gator XUV865M Cab HVAC (Model year 2023) Gator XUV865M Open (Model year 2023) Gator XUV865R (Model year 2023) Gator XUV865R Signature Edition (Model year 2023)

Engine power	40.3 kW 54 hp
Cargo box dimensions	1143 x 305 x 1320 mm 45 x 12 x 52 in.
Cargo box capacity (weight)	454 kg 1000 lb
Towing capacity	Up to 1814 kg 4000 lb
Front suspension	Fully independent dual A-arm with adjustable coils; 203 mm (8 in.) of travel
Rear suspension	Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in.) of travel
Final drive	Park, high, low, neutral, reverse transaxle
Four wheel drive	Dash switch actuated four-wheel drive system
Fuel capacity	42.4 L 11.2 U.S. gal.

Type	4-cycle gas, electronic fuel injection (EFI)
Displacement	812 cc
Power	40.3 kW 54 hp
Cooling system	Liquid

Transmission	Continuously Variable Transmission (CVT) with clutch enclosure
Final drive	Park, high, low, neutral, reverse transaxle
Four wheel drive	Dash switch actuated four-wheel drive system
Traction assist	Limited slip front differential, Positive locking, switch actuated rear differential lock
Descent control	Yes

Front	Fully independent dual A-arm with adjustable coils; 203 mm (8 in.) of travel
Rear	Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in.) of travel

Type	Front/rear hydraulic disc with twin piston front calipers
Park brake	Park in-transmission, Optional factory-installed secondary foot operated with hand release

Front	27x9-R14 Maxxis® Bighorn® 2.0 extreme terrain radials on steel or alloy wheels 27x9-R14 Predator Heavy-Duty all-terrain radials on steel or alloy wheels
Rear	27x11-R14 Maxxis Bighorn 2.0 extreme terrain radials on steel or alloy wheels 27x11-R14 Predator Heavy-Duty all-terrain radials on steel or alloy wheels

Wheelbase	2146 mm 84.5 in.
Weight	With fuel and fluids: 1022 kg 2253 lb
Length	3228 mm 127 in.
Width	1763 mm 69.4 in.
Height	1987 mm 78.2 in.
Tread centers	Front: 1341 mm 52.8 in. Rear: 1259 mm 49.6 in.
Ground clearance	284 mm 11.2 in.
Fuel capacity	42.4 L 11.2 U.S. gal.
Cargo box dimensions	1143 x 305 x 1320 mm 45 x 12 x 52 in.
Cargo box capacity (weight)	454 kg 1000 lb
Payload capacity	523 kg 1153 lb
Towing capacity	Up to 1814 kg 4000 lb
Hitch	Standard receiver: 5.1 cm 2 in.

Color	Green and yellow, TrueTimber® KANATI® camo, olive and black
Power steering	Yes
Battery / Alternator / Power port	Battery: 12 V 480 CCA Alternator: 85 amp DC outlet: 12 V
Instrumentation	Digital display (gear position, system diagnostic light, speed, rpm, 4WD indicator, rear differential indicator, fuel level, coolant temperature, hour meter, miles, and service interval warning light)
Storage	Total: 69.5 L 18.4 gal. Six cup holders: 4.6 L 1.2 gal. Center tray: 1.2 L 0.3 gal. Two dash bins: 3.3 L 0.9 gal. Storage pocket: 1.4 L 0.4 gal. Glove box: 3.8 L 1.0 gal. Under seat: 55.3 L 14.6 gal.
Seating	Black vinyl 40/60 split three-passenger bench

Country of Manufacture	U.S.
Date collected	8-Jun-22
